Name: STREACOM DB1 ULTRA COMPACT FANLESS ITX CASE
SKU: 368941

Product Details ＋

The DB1 is an ultra-compact fanless ITX case, designed to be paired with the new generation of APU/IGPUs, that is both competitively priced and built without any sacrifice on design or quality.

With a total volume less than 5l, the DB1 is our most compact fanless case but can still comfortably handle 45W of cooling, which is ideal for power-efficient systems based, especially when combined with the new generation of APU/IGPUs that deliver excellent performance/watt.

The DB1 is constructed from 4mm thick aluminium panels, a 21mm thick extruded heat sink, solid aluminium rods and is made using CNC milling and finished with sandblasted/anodised surface treatment, but despite using these premium materials, processing and finishing, is extremely competitively priced.

PRODUCT SPECIFICATIONS:

Form Factor: Ultra Compact Small Form Factor (SFF), mini tower, Mini-ITX motherboard support
Expansion: No support for PCIe expansion
PSU: Nano type PSU (external AC DC PCB)
Drives: Support for 1 x 2.5" drive and m.2 provided by the motherboard
CPU Cooling: 45W of CPU cooling, 2 x 6mm Heat Pipes
Dimensions: 222 x 222 x 101mm (D x H x W)
Weight: 1.9kg NET 2.5kg GROSS (packed weight)
Ports: Included USB Type-A 3.0 (Optional Type-C 3.1 Gen2)
Material: Aluminium 6063 for heat sink, side, front and back panels, acrylic upper and lower panels
Finish: Sandblast and anodized surface treatment, available in black and silver

VERSATILE AND MODULAR

The DB1 was of course design to work primarily in the vertical orientation as that occupies the least amount of desk space and also gives the best cooling performance as convection is optimised. It can however also be used in the horizontal orientation with the ability to position the front I/O at either side of the case.

THE CASE IS THE COOLER.

The approach to fanless, the cooling is done by the case itself and the DB1 is no exception. Heat is transferred from the CPU to the heat sink (side panel) using 6mm copper heat pipes and dissipated into the environment along its surface and fins which are optimised for natural convection.

ULTRA COMPACT DESIGN

It’s hard to appreciate just how small and tightly packed some our compact cases are, to the extent that we sometimes get asked if it’s possible to install an SFX or even ATX PSU inside them. For some context, the DB1 is not much larger than the ITX motherboard it holds, and this ultra small form factor is only made possible by the use of a NanoPSU that plugs directly into the motherboard.

DESIGN SIMPLICITY AND MODULARITY

It's hard to overstate just how simple and ingenious the design is. The entire case can be disassembled with just 4 screws making installation of the motherboard and CPU cooler easier. As the case is symmetrical, the panels can be rearranged to the front I/O is modular meaning it can be replaced with an alternative port.
